The entry level that runs up to 48 hours non-stop
The DF200 is the entry-level lab solution for producing temporary and definitive prosthetic restorations. With the optional four-position disc loader it reaches an autonomy of up to 48 hours non-stop. It comes standard with the pneumatic disc release system, to pause a job, change the holder and resume later.
The 4-position disc loader (optional) extends autonomous production to up to 48 hours.
Pause, change holder and job, and resume without losing the work.
Disc milling at 90° for superior esthetic quality.
Technology is in Dental Four's DNA: we look to innovation as a key factor in helping labs grow, increasing productivity and cutting costs.
Latest-generation components ensuring maximum precision and long-term durability.
An intuitive interface for immediate use: it shortens the learning curve and increases productivity.
A proprietary AI algorithm performs continuous predictive maintenance, minimizing machine downtime.
Designed to energy-saving criteria (ISO 14955): lower consumption and reduced operating costs.
The compact, high-rigidity mechanics, advanced electronics management and high-quality components guarantee levels of precision and speed at the top of the category.
The stainless-steel work chamber is integrated into the frame: maximum robustness and rigidity, easy cleaning and dust/liquid tightness.
The extraction nozzle is fixed to the spindle to work close to the tool; adjustable air nozzles ensure consistently optimal cooling and spraying.
The wide axis tilt angles allow restorations with significant divergences on titanium and chrome-cobalt and, with the C-Clamp, buccal-region machining.
Every machine includes an initial equipment kit with milling cutters for advanced machining, such as angled holes and threading.
The DF200 precisely machines a wide range of materials, for high-quality prosthetics.
Systems designed to let the machine work autonomously, reducing downtime and operator intervention.
The system removes the disc holder being machined and repositions it in exactly the same spot. Combined with the Stop&Go system, it lets you pause a job, load another even on different materials, and resume it later.
To ensure the best chip extraction, the extraction nozzle is fixed to the spindle, so it works in the area closest to the tool. The air-blast nozzles for cooling and liquid spraying are also fixed to the spindle, always guaranteeing correct lubrication.
The lubrication kit for wet milling is available as an option.
A workflow that grows with you: from everyday use to unattended production, without adding operational complexity.
Up to 48 hours of autonomous, unattended production; the pneumatic disc release system makes the workflow more efficient and flexible.
The DF PANEL interface makes operation immediate and hassle-free, shortening the learning curve and increasing productivity even for less experienced operators.
All our products are compatible with the leading CAM software on the market. Thanks to a «certified» strategy package, we guarantee a minimal learning curve and immediate productivity even for less experienced operators.
Customize the machine with accessories and supports designed for your workflow.
| Milling system | 5 continuous axes |
| Spindle | 750 W · 60.000 rpm |
| Tool holder | 3 mm |
| Tool change | Automatic, 12 positions |
| Motors | Stepper with encoder |
| Axis rotation | A axis harmonic drive · B axis epicyclic class p0 |
| Rotation angle | A = 360° · B = ± 40° |
| Loader | Automatic disc, 4 positions (optional) |
| Lubrication | Optional |
| Dimensions | 720 × 650 × 740 mm |
| Weight | 115 kg |
